ZKTECO Mini AC Plus

Product Features:

  • Compact, sleek, and portable design
  • Linux-based OS with visible light facial recognition
  • Recognition range extended up to 2 meters
  • Multiple verification: Face, Palm (optional), Card, Password



 48,500

Description

ZKTECO Mini AC Plus:

Smartcore ZKTECO Mini AC Plus is a compact, Linux-based access control and time attendance terminal engineered with Visible Light Facial Recognition technology to deliver high-performance biometric authentication in a sleek and portable design. Ideal for modern, hygiene-conscious workplaces, it offers a fully touchless user experience, supporting multiple verification modes including facial recognition, palm recognition (optional), RFID card, and password. With a recognition range of up to 2 meters, the Mini AC Plus enables faster throughput and improved user convenience. Equipped with a 5-inch touchscreen, 2MP WDR low-light camera, and adjustable LED brightness, the terminal operates with precision in varying lighting conditions. It supports up to 3,000 face templates, 1,500 palm records, and 150,000 transaction logs.

Technical Specification

Display5-inch Touch Screen
Operating SystemLinux
Face Capacity3,000
Palm Capacity1,500 (Optional)
Card Capacity3,000
Transaction Capacity150,000
Biometric AlgorithmsZKFace VX5.8 / ZKPalm VX12.0
Recognition Speed≤ 1 second
CommunicationTCP/IP, RS485, Wiegand I/O, Wi-Fi (Optional)
Hardware900MHz Dual-Core CPU, 512MB RAM, 8GB ROM, 2MP WDR Camera, Adjustable LED Brightness
Access Control InterfacesElectric Lock, Door Sensor, Exit Button, Alarm Output, Auxiliary Input
Card Types125KHz EM, 13.56MHz IC (Optional)
Power Supply12V 3A
Operating Temperature-10°C to 45°C
Operating Humidity10% to 90%
Dimensions (W × H × D)91.93 × 202.93 × 21.5 mm
Supported SoftwareEasyTimePro / ZKBioSecurity
